YPH105E YT204001-FC ABB 10.1" Touch HMI for Drives & PLCs

Product Snapshot

The YPH105E (order code YT204001-FC) is a 10.1-inch capacitive-touch HMI designed for ABB industrial drives and PLCs. Featuring built-in EtherCAT, Modbus-TCP and CANopen ports, plus drive-optimized faceplates, this HMI allows operators to start, stop and monitor any ACS880, DCS-800 or AC 500 system without requiring external gateways. With an IP66 front panel, SIL 2 emergency-stop input and multilingual help, it's ideal for demanding applications including cranes, mills, pumps and marine consoles.

Key Features & Benefits

10.1" multi-touch display - 1280 × 800 resolution, 400 nits brightness, anti-glare coating, glove and wet-hand capable
Triple Ethernet connectivity - 2 × Gigabit Ethernet + 1 × EtherCAT with 1 ms cycle time and redundant ring capability
Pre-installed drive faceplates - includes start/stop, torque, power, temperature monitoring and alarm displays
14 on-board I/O points - 8 digital inputs, 4 digital outputs, 2 analog inputs; 24 VDC, 1 ms scan time, isolated
SIL 2 / PL-d safety rating - dual-channel emergency-stop input with diagnostics per IEC 61508
Wash-down IP66 front panel - IK08 impact resistance, 5 g vibration tolerance, operating range -20…+60 °C
Global certifications - CE, UL 508, cULus, ABS marine, RoHS, REACH compliant

Technical Specifications

Parameter	Value
Part Number	YT204001-FC
ABB Type	YPH105E
Display	10.1" TFT, 1280 × 800, 400 cd/m²
Touch	Capacitive multi-touch, anti-glare
Network	2 × Gig-E, 1 × EtherCAT, 1 × RS-485, CAN
On-board I/O	8 DI, 4 DO, 2 AI (12-bit), 24 VDC
Processor	ARM Cortex-A9 dual-core @ 800 MHz
Memory	1 GB DDR3, 4 GB Flash, SD slot
OS	Linux 4.x + ABB CP600 Pro runtime
Supply	24 VDC ±20 %, 15 W max
Isolation	1 500 V RMS comm-to-logic
Operating Temp	-20 - +60 °C
Storage Temp	-30 - +70 °C
Humidity	95 % RH non-condensing
Front Protection	IP66 / IK08
Rear Protection	IP20
Dimensions	275 × 195 × 45 mm (W×H×D)
Weight	1.4 kg
Certifications	CE, UL 508, cULus, ABS, SIL 2, RoHS

Typical Applications

ACS880 crane drives (hoist & travel control)
DCS-800 rolling-mill stands (tension & torque monitoring)
AC 500 pump skids (flow & pressure set-point adjustment)
Marine thruster drives (ABS approved for marine use)
Remote island substations (as SCADA node)

Compatible Hardware

Drives: ACS880-01, ACS880-04, ACS880-07, DCS-800 (all frames)
PLCs: AC 500-eCo, AC 800M, AC 900F (via EtherCAT)
Software: Panel Builder 600, Drive composer plug-in
Legacy Upgrade: Replaces CP450-T, CP451-ETH with adaptor plate

Installation & Start-up

Cut panel hole - 261 × 180 mm (W×H); torque clamps to 1.2 N*m.
Connect 24 V power - observe polarity; green "PWR" LED will illuminate.
Plug in EtherCAT - connect port-1 to drive, port-2 to plant network; green "ECAT" LED indicates sync status.
Import project - use Panel Builder 600 software; drag-and-drop drive faceplate.
Download runtime - approximately 30 seconds via USB or Ethernet; configure language, units, and passwords.
Test screen - navigate to drive control, start motor, view torque trend.
