High Speed ABB Module QHFT200F YL681001-AF ABB 200 A DC Fuse Holder

QHFT200F (order code YL681001-AF) is a 200 A, 690 V DC high-speed fuse link complete with touch-safe front-indicator holder. Ultra-rapid arc-quenching (< 1 ms) protects IGBT bridges, DC-bus capacitors and semiconductor contactors inside ABB DCS/ACS drives, ensuring SIL 2 / IEC 60269-4 compliance for paper, metals, crane and marine applications.

• 200 A rated current - continuous operation up to 45 °C without derating
• 690 V DC max. voltage - suits 400-690 V AC drives (540-930 V DC bus)
• Ultra-rapid interruption - I²t let-through < 18 000 A²s @ 200 kA prospective
• Visual striker - front red pin pops when blown, visible with door closed
• Touch-safe holder - IP20 fingersafe, lockable in open position
• Low watts-loss - < 18 W @ rated current, reduces panel heating
• Global approvals - CE, UL 248-13, IEC 60269-4, RoHS, REACH

• DCS-800 / ACS-880 DC-bus protection (540-930 V)
• Metals reversing-mill DC bridges
• Crane hoist VFD semiconductor protection
• Marine thruster drives (ABS approved)
• Large test-bench power supplies

• DC Drives: DCS-800 (frames B-R), DCS-600 (retrofit)
• AC Drives: ACS-880-04, ACS-880-07 (common DC bus)
• Fuse Holders: YL681001-AF (included), QHFT-200-HL (remote)
• Monitoring: 1SBP260020R1001 micro-switch (optional blown indication)

1. De-energise drive - lock-out/tag-out per local code.
2. Insert fuse - slide into holder until latch clicks; red pin flush.
3. Torque bus bars - 12 N*m (M8) or 18 N*m (M10) per ABB manual.
4. Power-up - green "DC" LED on drive; record initial current.
5. Annual check - IR scan < 1 mΩ contact resistance, no discoloration.
6. Replace after blow - red pin visible; reset micro-switch if fitted.
