UNS0868A-P V1 HIEE305120R0001 ABB Advant OCS CPU Processor Module

Product Snapshot

UNS0868A-P V1 (order code HIEE305120R0001) is the central processor module for ABB Advant OCS racks. The board combines a 32-bit RISC CPU, flash memory and triple communication ports to execute real-time control, redundancy logic and plant-wide data exchange for power, paper, metals and marine applications.

Key Features & Benefits

32-bit RISC core - 60 MHz, < 5 ms control loop, deterministic interrupt latency
8 MB flash + 16 MB RAM - stores 500 000 lines of IEC 61131 code and 30 days of 1-second trend data
Triple on-board ports - RS-232 service, RS-485/Modbus, CANopen master
Redundancy-ready - dual-CPU sync link, bumpless switch-over < 10 ms
Hot-swap capable - swap under power in ≤ 30 s when rack load ≤ 70 %
Wide temperature - 0…+60 °C operating, -40…+85 °C storage
Global approvals - CE, UL 508, ABS marine, SIL 2, RoHS, REACH

Technical Specifications

Parameter	Value
Part Number	HIEE305120R0001
ABB Type	UNS0868A-P V1
Function	Advant OCS CPU processor module
Processor	32-bit RISC, 60 MHz
Memory	8 MB Flash, 16 MB SDRAM
Control Loop	< 5 ms (typical 2 ms)
Interfaces	RS-232 service, RS-485/Modbus, CANopen
Isolation	1 500 V RMS comm-to-logic
Supply	5 VDC @ 1.2 A from rack backplane
Dimensions	128 × 22.5 × 115 mm (1-slot)
Weight	0.2 kg
Operating Temp	0 - 60 °C
Storage Temp	-40 - +85 °C
Humidity	95 % RH non-condensing
Protection	IP20
Certifications	CE, UL 508, ABS, SIL 2, RoHS

Typical Applications

Paper-machine sectional drives (speed & tension)
Metals reversing-mill DC bridges (torque control)
Power-plant coal-mill feeders (flow loops)
Marine thruster drives (ABS certified)
Retrofit of legacy Advant Controller 31x/41x/51x racks

Compatible Hardware

Racks: 07 KR 91, 07 KT 92, 07 SK 50 (1-slot width)
Power Supply: SAFT112POW 24 VDC (recommended)
Communication: CI-930F (Profibus), CI-867K01 (Ethernet)
Legacy Upgrade: Replaces UNS0867A-P with firmware ≥ v6.2

Installation & Start-up

Slide module into 35 mm DIN-rail; latch until click.
Connect 24 V - observe polarity; green "PWR" LED lights.
Load firmware - use Advant Station 500, import *.img file.
Configure redundancy - set CPU ID, sync link, bumpless switch-over.
Test logic - force DO, read AI, verify scan time < 5 ms.

LED Diagnostics

LED	Color	Meaning
PWR	Green	5 V logic supply OK
RUN	Green	CPU executing
SYNC	Yellow	Redundancy sync active
FLT	Red	Watchdog, memory, comm fault
