QHFT200F YL681001-AF ABB 200A High Speed DC Fuse Holder Touch Safe 690V

Product Details:

Place of Origin:	Finland
Brand Name:	ABB
Certification:	COC
Model Number:	QHFT200F

Payment & Shipping Terms:

Price:	$999
Payment Terms:	T/T

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	High Speed QHFT200F YL681001-AF ABB , 200A QHFT200F YL681001-AF ABB , 690V DC Fuse Holder

QHFT200F YL681001-AF ABB 200 A High-Speed DC Fuse & Holder

Product Snapshot

QHFT200F (order code YL681001-AF) is a 200 A, 690 V DC high-speed fuse link complete with touch-safe front-indicator holder. Ultra-rapid arc-quenching (< 1 ms) protects IGBT bridges, DC-bus capacitors and semiconductor contactors inside ABB DCS/ACS drives, ensuring SIL 2 / IEC 60269-4 compliance for paper, metals, crane and marine applications.

Key Features & Benefits

200 A rated current - continuous operation up to 45 °C without derating
690 V DC max. voltage - suits 400-690 V AC drives (540-930 V DC bus)
Ultra-rapid interruption - I²t let-through < 18 000 A²s @ 200 kA prospective
Visual striker - front red pin pops when blown, visible with door closed
Touch-safe holder - IP20 fingersafe, lockable in open position
Low watts-loss - < 18 W @ rated current, reduces panel heating
Global approvals - CE, UL 248-13, IEC 60269-4, RoHS, REACH

Technical Specifications

Parameter	Value
Part Number	QHFT200F YL681001-AF
Rated Current	200 A
Rated Voltage DC	690 V (400-690 V AC drives)
Breaking Capacity	200 kA @ 690 V DC
I²t let-through	< 18 000 A²s (pre-arcing)
Watts-loss @ 200 A	< 18 W
Operating Temp	-40…+70 °C (derate 1 %/K > 45 °C)
Storage Temp	-50…+90 °C
Humidity	95 % RH non-condensing
Dimensions (fuse)	80 × 38 × 95 mm (L×W×H)
Holder	Front-indicator, lockable, IP20
Weight (complete)	0.65 kg
Standards	IEC 60269-4, UL 248-13, CE, RoHS

Typical Applications

DCS-800 / ACS-880 DC-bus protection (540-930 V)
Metals reversing-mill DC bridges
Crane hoist VFD semiconductor protection
Marine thruster drives (ABS approved)
Large test-bench power supplies

Compatible ABB Drives / Hardware

DC Drives: DCS-800 (frames B-R), DCS-600 (retrofit)
AC Drives: ACS-880-04, ACS-880-07 (common DC bus)
Fuse Holders: YL681001-AF (included), QHFT-200-HL (remote)
Monitoring: 1SBP260020R1001 micro-switch (optional blown indication)

Installation & Maintenance

De-energise drive - lock-out/tag-out per local code.
Insert fuse - slide into holder until latch clicks; red pin flush.
Torque bus bars - 12 N*m (M8) or 18 N*m (M10) per ABB manual.
Power-up - green "DC" LED on drive; record initial current.
Annual check - IR scan < 1 mΩ contact resistance, no discoloration.
Replace after blow - red pin visible; reset micro-switch if fitted.

LED / Striker Indication

Indicator	Status	Meaning
Red pin	Flush	Fuse healthy
Red pin	Extended	Fuse blown (fault cleared)
Micro-switch	Open	Remote blown signal to PLC
