Name: UNS 0863A-P,V1 HIEE305082R0001 ABB Advant OCS Communication I/O Processor
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: HIEE305082R0001
Price: 399 USD
Availability: InStock

Home Products ABB Module

UNS 0863A-P,V1 HIEE305082R0001 ABB Advant OCS Communication I/O Processor

Product Details:

Place of Origin:	Finland
Brand Name:	ABB
Certification:	COC
Model Number:	HIEE305082R0001

Payment & Shipping Terms:

Price:	$399
Payment Terms:	T/T

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	Communication HIEE305082R0001 ABB , Advant OCS HIEE305082R0001 ABB , Communication ABB IO Module

UNS 0863A-P,V1 HIEE305082R0001 ABB Advant OCS Communication & I/O Processor

Product Snapshot

UNS 0863A-P,V1 (order code HIEE305082R0001) is a combined communication and I/O processor for ABB Advant OCS racks. The board hosts two independent field-bus interfaces, 12 on-board digital I/O and real-time data logging, eliminating external gateways and reducing panel wiring by > 30% in paper, metals, power and marine applications.

Key Features & Benefits

Dual-field-bus on-board - isolated RS-485 + CANopen master, 1 Mbps max.
12 digital I/O - 8 DI, 4 DO, 24 VDC, IEC 61131-2 type 3, 1 ms scan
32-bit RISC CPU - 60 MHz, < 3 ms control loop, deterministic interrupt
8 MB flash + 16 MB SDRAM - 500,000 lines of code, 7-day circular log
Redundancy-ready - dual-CPU sync link, bumpless switch-over < 10 ms
Hot-swap capable - swap under power in ≤ 30 s when rack load ≤ 70%
Wide temperature - 0...+60 °C operating, -40...+85 °C storage
Global approvals - CE, UL 508, ABS marine, SIL 2, RoHS, REACH

Technical Specifications

Parameter	Value
Part Number	HIEE305082R0001
ABB Type	UNS 0863A-P,V1
Function	Comm. & I/O processor
Processor	32-bit RISC, 60 MHz
Memory	8 MB Flash, 16 MB SDRAM
Control Loop	< 3 ms (typical 1 ms)
Digital Inputs	8 × 24 VDC, 2 ms filter
Digital Outputs	4 × 24 VDC, 0.5 A, short-circuit proof
Field-Bus	RS-485 (Modbus-RTU), CANopen master
Baud Rate	300 - 1,000 kbps (auto-detect)
Isolation	1,500 V RMS comm-to-logic
Supply	5 VDC @ 1 A from rack backplane
Dimensions	128 × 22.5 × 115 mm (1-slot)
Weight	0.19 kg
Operating Temp	0 - 60 °C
Storage Temp	-40 - +85 °C
Humidity	95% RH non-condensing
Protection	IP20
Certifications	CE, UL 508, ABS, SIL 2, RoHS

Typical Applications

Paper-machine sectional drives (speed & tension)
Metals reversing-mill DC bridges (torque control)
Power-plant coal-mill feeders (flow loops)
Marine thruster drives (ABS certified)
Retrofit of legacy Advant Controller 31x/41x racks

Compatible Hardware

Racks: 07 KR 91, 07 KT 92, 07 SK 50 (1-slot width)
Power Supply: SAFT112POW 24 VDC (recommended)
Communication: CI-930F (Profibus), CI-867K01 (Ethernet)
Legacy Upgrade: Replaces UNS 0862A-P with firmware ≥ v6.3

Installation & Start-up

Slide module into 35 mm DIN-rail; latch until click.
Connect 24 V - observe polarity; green "PWR" LED lights.
Wire field-bus - use shielded twisted-pair, 120 Ω termination.
Configure controller - set node-ID, baud-rate, I/O mapping.
Test I/O - force DO, read DI, verify scan time < 3 ms.

LED Diagnostics

LED	Color	Meaning
PWR	Green	5 V logic supply OK
RUN	Green	CPU executing
TX/RX	Yellow blink	Field-bus traffic
FLT	Red	Watchdog, comm, I/O fault
