Advant Controller 07KT98 GJR5253100R0260 ABB 31 CPU Module 24V DC 50 MHz

Advant Controller 07KT98 GJR5253100R0260 ABB 31 CPU Module 24V DC 50 MHz

  • Advant Controller 07KT98 GJR5253100R0260 ABB 31 CPU Module 24V DC 50 MHz
Advant Controller 07KT98 GJR5253100R0260 ABB 31 CPU Module 24V DC 50 MHz
Product Details:
Place of Origin: USA
Certification: COC
Payment & Shipping Terms:
Price: $9999
Payment Terms: T/T
Contact Now
Detailed Product Description
Type: Module Shipping By: DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time: In Stock Product Type: Module
Payment: T/T Trading Term: EXW
Highlight:

Advant Controller 07KT98 GJR5253100R0260 ABB

,

50 MHz 07KT98 GJR5253100R0260 ABB

,

Advant Controller PCB CPU Module

07KT98 GJR5253100R0260 ABB Advant Controller 31 Enhanced CPU Module
Product Description
The 07KT98 is a genuine ABB Advant Controller 31 (AC31) enhanced CPU with integrated Ethernet, 1 MB battery-backed RAM and 24 VDC power. Designed for distributed automation and safety-critical applications, it delivers deterministic control, hot-swap capability and SIL 2 fault tolerance for turbines, compressors and industrial machinery.
Key Features & Benefits
  • 100% OEM ABB - serialized & factory-sealed
  • Integrated 10/100 Ethernet (RJ-45) for programming & SCADA
  • 1 MB battery-backed RAM, 4 MB flash
  • 24 VDC power, 50 MHz Motorola ColdFire CPU
  • 0.1 ms per 1 K instructions typical scan
  • 512 digital I/O or 128 analog I/O expandable to 4,096
  • Real-time clock & battery for SRAM retention
  • Hot-swap in AC31 rack - no shutdown required
  • -25°C to +60°C operating range, conformal-coated
  • SIL 2 (IEC 61508), CE, UL 508, ATEX, IECEx certified
Technical Specifications
Parameter Value
Model 07KT98
Part Number GJR5253100R0260
Series Advant Controller 31 (AC31)
CPU Motorola ColdFire 50 MHz
Memory 1 MB RAM, 4 MB flash
I/O Capacity 512 DI/DO or 128 AI/AO (4,096 max)
Scan Time 0.1 ms per 1 K instructions
Communication 10/100 Ethernet, RS-232, RS-485
RTC Yes, battery-backed
Power 24 VDC ±20%, 10 W max
Operating Temp -25°C to +60°C
Humidity 5% to 95% RH non-condensing
Mounting DIN-rail 35 mm or panel
Approvals SIL 2, CE, UL 508, ATEX Zone 2, IECEx
Typical Applications
  • Gas/steam turbine auxiliary control
  • Compressor sequencing and protection
  • Generator excitation and synchronization
  • Safety-system discrete & analog control (SIL 2)
  • Industrial automation retrofits
What's in the Box
  • 1× 07KT98 CPU module
  • 1× Removable power & communication terminal block
  • Factory calibration certificate & traceability label
  • Quick-start guide & ESD wrist strap
Ordering Information
ABB Part Number: 07KT98 (GJR5253100R0260)
GTIN: 7320500982600
Warranty: 24-month advance-replacement warranty
Installation & Setup
  1. Mount on DIN-rail or panel.
  2. Connect 24 VDC power and Ethernet/serial cables.
  3. Power on--green RUN LED flashes then steady.
  4. Configure I/O and communication in ABB Automation Builder.
  5. Perform loop test & SIL 2 proof-test.
Certifications & Compliance
  • SIL 2 (IEC 61508) suitable
  • CE, UL 508, CSA C22.2 No. 142
  • ATEX Zone 2, IECEx Ex ec IIC T4 Gc
