XLPE Insulation SIEMENS 6SL3162-2ME01-0AC0 SINAMICS S120 C/D Motor Adapter Cable

The 6SL3162-2ME01-0AC0 is a factory-made C/D motor-adapter cable designed to connect SINAMICS S120 3-18 A Motor Modules to shielded motor leads. This complete assembly integrates strain-relief, EMC shield clamp, and touch-safe insulation, reducing installation time by up to 30% while ensuring full compliance with IEC 61800-5-1 and EN 60204-1 standards.

• Plug-and-play complete cable and connector kit - no crimping required
• 3-18 A rating compatible with S120 Motor Modules frame sizes C & D
• 2.5 mm² conductors - Copper, class 5, with 90 °C/1000 V XLPE insulation
• EMC-ready design with integral shield clamp & strain-relief (impedance < 1 mΩ)
• Touch-safe IP20 fingersafe shroud (IP54 when mated)
• 80 cm standard length - ideal for door-mounted starters without excess loops
• UL/CE dual marked - UL AWM 2587 1000 V, CE low-voltage directive compliant
• Wide temperature range: -30…+80 °C static, -5…+50 °C flexing
• Global certifications including RoHS, REACH, and optional ATEX category 3

• S120 vector drives for extruders, mixers, and conveyors
• Servo in-feed modules for packaging machines
• Pump and fan VFD skids (frame C 5.5-11 kW)
• ATEX Zone 22 dust-handling conveyors (with Ex e motor)
• Panel-builder retrofit from 3300 to S120 without re-crimping

• 6SL3210-1SE21-8UA0 - 11 kW, 22 A, frame C
• 6SL3210-1SE17-7UA0 - 5.5 kW, 11 A, frame C
• 6SL3210-1SE22-5UA0 - 15 kW, 30 A, frame D
• 6SL3210-1SE16-0UA0 - 3 kW, 7 A, frame C

All part numbers above ship with C/D connector; this cable completes the connection.

1. De-energise drive - implement lock-out/tag-out per local safety code.
2. Snap cable onto Motor Module until latch audibly clicks.
3. Route motor leads through EMC gland and tighten shield clamp securely.
4. Connect motor conductors to plug per color code; torque to 0.8 N*m.
5. Close IP54 shroud and verify green "READY" LED illuminates on module.
