Expansion Module Siemens PLC Siemens 6ES7214-1BD23-0XB8 S7-200 For 2 Analog Outputs

Expansion Module Siemens PLC Siemens 6ES7214-1BD23-0XB8 S7-200 For 2 Analog Outputs

  • Expansion Module Siemens PLC Siemens 6ES7214-1BD23-0XB8 S7-200 For 2 Analog Outputs
Expansion Module Siemens PLC Siemens 6ES7214-1BD23-0XB8 S7-200 For 2 Analog Outputs
Product Details:
Place of Origin: China
Brand Name: Siemens
Certification: COC
Model Number: 6ES7214-1BD23-0XB8
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $99
Packaging Details: original
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10 pieces one day
Contact Now
Detailed Product Description
Type: Module Shipping By: DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time: In Stock Product Type: Module
Payment: T/T Trading Term: EXW
Highlight:

Expansion Module Siemens PLC

,

2 Analog Outputs Siemens PLC

,

Expansion Module Siemens 6ES7214-1BD23-0XB8

6ES7214-1BD23-0XB8 Siemens | S7-200 Expansion Module for 2 Analog Outputs
Product Snapshot
6ES7214-1BD23-0XB8 is an expansion module for SIMATIC S7-200 PLCs, offering two 12-bit analog outputs. This module is designed to provide precise control of analog signals for applications in automation and process control systems, such as temperature control, motor speed adjustment, and liquid level management.

Key Features & Benefits
  • Dual Analog Outputs: Two 12-bit analog output channels
  • Wide Range of Signals: Supports 0-10 V and 0-20 mA signals
  • High Accuracy: ±0.5% accuracy for precise control
  • Programmable: Easily configure output ranges and types via STEP 7-Micro/WIN
  • Compact Design: Fits within the compact S7-200 form factor
  • Easy Integration: Compatible with all S7-200 CPUs
  • Global Approvals: UL, CE, RoHS, REACH compliant

Technical Specifications
Parameter Value
Part Number 6ES7214-1BD23-0XB8
Series SIMATIC S7-200
Function 2-channel 12-bit Analog Output Module
Output Range 0-10 V, 0-20 mA
Accuracy ±0.5% of full scale
Load Capability 2 mA (0-10 V), 20 mA (0-20 mA)
Update Rate 3 ms per channel
Isolation 500 Vrms channel-to-channel
Power Consumption 5 VDC @ 20 mA (from PLC backplane)
Operating Temperature 0-55 °C
Storage Temperature -25-+70 °C
Humidity 95% RH non-condensing
Dimensions (W*H*D) 71 mm * 80 mm * 62 mm
Weight 0.19 kg
Certifications UL, CE, RoHS, REACH

Typical Applications
  • Temperature control in HVAC systems
  • Motor speed adjustment in industrial machinery
  • Liquid level control in tanks
  • Pressure control in hydraulic systems
  • Process control in manufacturing plants

Compatible Hardware
  • PLCs: S7-200 CN CPUs (224, 224 XP, 226)
  • Cables: Standard PLC ribbon cable
  • Power Supply: 24 VDC power supply for PLC system
  • Software: STEP 7-Micro/WIN V4.0 or higher

Installation & Configuration
  1. Insert Module: Slide the module into an available slot on the PLC rail.
  2. Connect PLC Ribbon Cable: Ensure the ribbon cable is properly connected.
  3. Power Up PLC: Turn on the PLC and wait for the status LEDs to stabilize.
  4. Configure Outputs: Use STEP 7-Micro/WIN to set the output ranges and signal types.
  5. Test Outputs: Check the analog outputs using a multimeter to ensure they match the configured values.
