VersaMax IC200ETM001 GE Ethernet Network Interface Module Multi Protocol

Product Details:

Place of Origin:	USA
Brand Name:	GE
Certification:	COC
Model Number:	IC200ETM001

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$80-180
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	VersaMax IC200ETM001 GE , Multi Protocol IC200ETM001 GE , Ethernet Network Interface Module

IC200ETM001 GE | VersaMax Ethernet Network Interface Module

Product Snapshot

The IC200ETM001 is a single-width Ethernet Network Interface that transforms any VersaMax I/O rack into a stand-alone remote I/O node. Featuring one 10/100 Mbps RJ-45 port, this module supports Modbus TCP (server & client), Ethernet Global Data (EGD), and SRTP for seamless communication with HMIs, SCADA, MES, and cloud platforms. Built-in switch technology eliminates external hubs and reduces panel wiring by up to 30%.

Key Features & Benefits

Multi-protocol - Supports Modbus TCP Server/Client, EGD, and SRTP in one module
10/100 Mbps auto-negotiating - Works automatically with straight or crossover CAT5e/CAT6 cables
256 Modbus registers - 128 read, 128 write, with configurable mapping
16 EGD exchanges - 2 kB producer/consumer data with < 5 ms update
Web server - Includes static diagnostics page and firmware upload via HTTP
Hot-swap ready - Can be inserted/removed under power when rack power budget ≤ 70%
Industrial temperature range - 0...+60°C operating, -40...+85°C storage, 5 g vibration resistant
Global certifications - CE, UL 508, CUL, RoHS, REACH compliant

Technical Specifications

Parameter	Value
Part Number	IC200ETM001
Series	VersaMax I/O
Function	Ethernet Network Interface
Port	1 * RJ-45 10/100 Mbps (copper)
Protocols	Modbus TCP Server/Client, EGD, SRTP
Modbus Registers	256 (128 RW, 128 RO)
EGD Exchanges	16 (2 kB max)
Cable Length	100 m max per segment
Isolation	1,500 V RMS Ethernet-to-logic
Power (5 V)	300 mA typical, 400 mA max
Power (3.3 V)	50 mA typical
MAC Address	Factory-unique, printed on label
Dimensions (WHD)	66.8 * 50 * 70 mm
Weight	0.08 kg
Operating Temp	0...+60°C
Storage Temp	-40...+85°C
Humidity	5...95% RH non-condensing

Typical Applications

Remote I/O for CompactLogix/ControlLogix via Modbus TCP
Water-treatment SCADA (Wonderware, iFIX)
Packaging line HMI (PanelView, Weintek)
Building-management BACnet gateways
Cloud data logging via MQTT bridge

Compatible Carriers

IC200CHS002 - box-style screw terminals (most popular)
IC200CHS005 - spring-clamp version for vibration zones
IC200CHS025 - compact spring carrier for space-critical panels

Quick Start Guide

Insert module in any VersaMax I/O slot; torque captive screws 0.4 N*m.
Wire port - use shielded CAT5e, ground shield at panel entry only.
Assign IP - rotary switches 0-999 for last octet, or DHCP via software.
Configure - Proficy ME > Hardware > ETM001 > Modbus/EGD tables.
Download - store config in CPU flash; cycle power optional.
Verify LEDs - green "LINK" steady, amber "ACT" blinks with traffic.

What's in the Box?

1 * IC200ETM001 Ethernet module, factory-sealed
1 * quick-start guide (English)
1 * RJ-45 dust cap (keeps unused port clean)
