VersaMax GE Fanuc PLC IC200ALG432 GE 8 Channel Analog Current Voltage Output Module

The IC200ALG432 is a high-density 8-channel analog output module designed to source ±10 V, 0-10 V, 0-5 V, 1-5 V, ±5 V, 0-20 mA or 4-20 mA signals to drives, valves and actuators. With 14-bit resolution, 2 ms update per channel and short-circuit protection, it delivers PLC-grade accuracy at the lowest cost-per-point in the VersaMax family. Ideal for water-treatment chemical dosing, packaging line drives, HVAC dampers and any OEM skid requiring reliable, isolated set-point control without external amplifiers.

• 8 software-selectable ranges - voltage or current on any channel
• 14-bit resolution - < 0.2% full-scale accuracy, ±0.1% linearity
• Short-circuit & open-wire protection - auto-limit at 24 mA, diagnostic bit provided
• 2 ms update per channel - 16 ms for all 8, configurable slew-rate limit
• Isolated outputs - 1500 V RMS field-to-logic, channel-to-channel 500 V
• 24 V loop supply included - 24 VDC @ 200 mA total, current-limited
• Hot-swap ready - insert/remove under power when used with IC200CHS002/005 carriers
• Global certs - CE, UL 508, CUL, RoHS; -40…+85 °C storage

• Water-treatment chemical dosing pumps (4-20 mA)
• Packaging line servo drives (±10 V)
• HVAC valve & damper position (2-10 V)
• Oil & gas choke valve control (4-20 mA)
• OEM skids needing 8 isolated set-points in 110 mm width

• IC200CHS002 - box-style screw terminals (most popular)
• IC200CHS005 - spring-clamp version for vibration zones
• IC200CHS001 - barrier-style for extra isolation

1. Use shielded twisted-pair - connect shield at panel entry only.
2. Torque terminals to 0.4 N*m - over-tightening may crack housing.
3. Maintain 25 mm clearance above module for hot-insertion.
4. Verify loop resistance - total ≤ 750 Ω (module 250 Ω + wire + load).
5. Enable 24 V supply in software if loop-powered devices are used.

• Select range per channel: voltage or current
• Set slew-rate limit 0-10 s for smooth valve movement
• Enable open-wire detect for current outputs
• Map diagnostic bits to %I or %M for short-circuit alarms

• 1 * IC200ALG432 analog output module, factory-sealed
• 1 * quick-start card (English)
• 1 * terminal torque label
