Name: 10MB Memory IC695CMU310 GE RX3i Max-ON Hot Standby Redundancy CPU
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: IC695CMU310
Price: 700.00 USD
Availability: InStock

Home Products GE Fanuc PLC

10MB Memory IC695CMU310 GE RX3i Max-ON Hot Standby Redundancy CPU

Product Details:

Place of Origin:	USA
Brand Name:	GE
Certification:	COC
Model Number:	IC695CMU310

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$600-800
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	10MB Memory IC695CMU310 GE , Redundancy CPU IC695CMU310 GE , 10MB Memory GE Fanuc Emerson

IC695CMU310 GE | RX3i Max-ON Hot-Standby Redundancy CPU

Product Snapshot

IC695CMU310 is a single-slot, hot-standby redundancy CPU that keeps critical processes running by switching from master to backup in ≤ 3 scans. With dual Ethernet ports, 10 MB battery-backed RAM and 10 MB flash, it is the heart of GE's Max-ON architecture for gas & steam turbines, standby power, boilers and high-availability manufacturing lines.

Key Features & Benefits

Max-ON redundancy - < 3-scan failover, zero I/O state loss
Dual Ethernet on-board - dedicated LAN for sync & health, no extra module needed
10 MB user memory - 5* larger than IC695CPU310; handles 512 program blocks ≤ 128 KB each
Fast Boolean execution - 0.195 ms / 1000 contacts; floating-point math included
Universal backplane - accepts RX3i PCI and Series 90-30 I/O in same rack
Embedded serial - 2 * isolated RS-232 + RS-485; Modbus RTU slave, SNP, Serial I/O
Hot-swap - slide-in design allows replacement without stopping the partner CPU
Industrial temp - 0…+60 °C operating, -40…+85 °C storage, 5 g vibration

Technical Specifications

Parameter	Value
Part Number	IC695CMU310
Function	Max-ON Hot-Standby Redundancy CPU
Slots Required	1 (single-slot)
User Memory	10 MB battery-backed RAM; 10 MB flash
Boolean Speed	0.195 ms / 1000 contacts typical
Program Blocks	512 max, 128 KB per block
Discrete %I/%Q	32 Kbits
Analog %AI/%AQ	32 Kwords configurable
Serial Ports	2 * RS-232 & RS-485 isolated
Serial Protocols	Modbus RTU Slave, SNP, Serial I/O
Ethernet Sync	2 * 10/100 Mbps dedicated LAN ports
Accuracy (TOD)	≤ 2 s drift per day
Power Draw	1.0 A @ +5 V; 1.25 A @ +3.3 V
Operating Temp	0…+60 °C
Storage Temp	-40…+85 °C
Dimensions (WHD)	66.8 * 133 * 122 mm
Weight	0.45 kg (1 lb)
Certifications	CE, UL 508, CUL, RoHS, PCI 2.2 compliant

Max-ON Redundancy Topology

Each system pair contains:

2 * IC695CMU310 (master & standby)
2 * IC695CHS0xx backplanes
2 * IC695PSxxxx power supplies
2 * IC695ETM001 (optional plant LAN)
Max-ON firmware & application

Fail-over occurs automatically via dedicated Ethernet LAN(s); I/O states and register data are synchronized every scan.

Typical Applications

Gas & steam turbine control
Stand-by power generation switch-gear
Boiler flame-safety and BMS
Continuous chemical reactors
High-availability packaging & material handling

Quick Start Steps

Insert CPU in slot 0 of each rack; torque screws 0.4 N*m.
Connect sync LAN (RJ-45) between CPUs; use CAT5e STP < 100 m.
Assign IP & redundancy role (master/standby) in Proficy ME.
Download application; Max-ON auto-synchronizes memory.
Verify LEDs - green "RUN" on master, green "STBY" on backup.

What's in the Box?

1 * IC695CMU310 CPU, factory-sealed
1 * quick-start guide (English)
2 * RJ-45 dust caps for sync ports
