Lightweight IC695ETM001 GE Ethernet Interface Module For RX3i PACSystems

The IC695ETM001 is a single-slot Ethernet Interface that turns any RX3i PACSystems rack into a powerful industrial Ethernet node. Featuring two auto-negotiating 10/100 Mbps RJ-45 ports, the module supports SRTP, Modbus TCP, Ethernet Global Data (EGD) and OPC-UA, allowing seamless communication between HMIs, SCADA, MES and cloud platforms. Built-in switch technology eliminates the need for external Ethernet hubs and reduces panel wiring by up to 30%.

• Dual-port switch - copper ports support daisy-chain, ring or redundant star topologies
• Deterministic update - < 1 ms EGD exchange time for 2 KB data with 16 consumers
• Cyber-secure - password-protected firmware upload, SSL/TLS 1.3 for OPC-UA, disabled-by-default web server
• Hot-swap ready - insert/remove under power when rack power budget ≤ 70%
• Auto-crossover - straight or crossover CAT5e/CAT6 cables work automatically
• Wide temperature - 0…+60 °C operating, -40…+85 °C storage, 5 g vibration, 50 g shock
• Global certs - CE, UL 508, CUL, ATEX (Cat 3, Zone 2), RoHS & REACH

• SRTP - upload/download logic, monitor variables, perform Run/Stop commands
• Modbus TCP - up to 16 concurrent server connections, 2 client channels
• Ethernet Global Data - 16 producers / 32 consumers, 2 KB per exchange
• OPC-UA - 10 concurrent sessions, 5 kHz sampling rate, built-in certificate manager
• Web server - static home page (can be disabled); firmware update via HTTPS

1. Slot module in any RX3i I/O slot; torque captive screws 0.4 N*m.
2. Wire ports - use CAT5e or higher, max 100 m; ports auto-MDIX.
3. Assign IP - Proficy Machine Edition > Hardware Configuration > ETM001 > Static or DHCP.
4. Configure protocols - enable SRTP, Modbus, EGD or OPC-UA as required.
5. Apply & download - store configuration in CPU flash; cycle power optional.
6. Verify LEDs - green "LAN" steady, amber "ACT" blinks with traffic.

• 1 * IC695ETM001 Ethernet module, factory-sealed
• 1 * quick-start guide (English)
• 2 * RJ-45 dust caps (keep unused ports clean)
