Name: YPM 106E (YT204001-FN) ABB 6-Inch Industrial Touch HMI Panel
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: YPM 106E
Price: 400.00 USD
Availability: InStock

Home Products ABB Module

YPM 106E (YT204001-FN) ABB 6-Inch Industrial Touch HMI Panel

Product Details:

Place of Origin:	Finland
Brand Name:	ABB
Certification:	COC
Model Number:	YPM 106E

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$300-500
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	ABB 6-inch industrial HMI panel , ABB touch HMI panel with warranty , YPM 106E industrial touchscreen panel

YPM 106E (YT204001-FN) ABB 6-Inch Industrial Touch HMI Panel

The YPM 106E is a genuine ABB 6-inch WVGA color operator panel with capacitive multi-touch and IP65 front. Designed for AC 500, AC 800M and legacy Advant systems, it offers wide 12-24 VDC supply, two Ethernet ports and compact mounting for demanding machines and process skids.

Key Features & Benefits

100% OEM ABB - serialized & factory-sealed
6" WVGA (800 × 480) TFT color display
Projected-capacitive multi-touch (PCAP)
IP65 front, IP20 rear enclosure
-20 °C … +60 °C operating range
2× Ethernet 10/100 + 1× RS-232/RS-485
USB 2.0 host & micro-SD slot for logs/recipes
12-24 VDC ±20%, < 7 W consumption
CE, UL 508, ATEX Zone 2, IECEx certified

Technical Specifications

Parameter	Value
Model	YPM 106E
Order Code	YT204001-FN
Display	6" WVGA, 800 × 480, 262k colors
Touch	Projected-capacitive, 10-point
Backlight	LED, 50,000 h MTBF
Interfaces	2× Ethernet 10/100, 1× RS-232/RS-485, USB 2.0
Memory	64 MB DRAM, 32 MB Flash + micro-SD
Power	12-24 VDC ±20%, 7 W max
Operating Temp	-20 °C … +60 °C
Humidity	5% … 95% RH non-condensing
Mounting	Panel-mount, 162 × 108 mm cut-out
Approvals	CE, UL 508, ATEX Zone 2, IECEx

Typical Applications

Compact machine operator panels
Chemical & pharmaceutical skids
Marine engine-room displays
Packaging & labeling machines
Water & wastewater SCADA

What's in the Box

1× YPM 106E HMI panel
1× Mounting gasket & screws
Factory calibration certificate
Quick-start guide & ESD wrist strap

Installation & Setup

Cut 162 × 108 mm panel opening; insert unit.
Connect 12-24 VDC and Ethernet/serial cables.
Power on--boot < 15 s.
Configure via Automation Builder or Panel Builder.
Verify touch calibration & network connectivity.
