6ES7222-1HF22-0XA0 Siemens | S7-200 CN CPU 222

Product Details:

Place of Origin:	Germany
Brand Name:	Siemens
Certification:	COC
Model Number:	6ES7222-1HF22-0XA0

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	Siemens S7-200 CN CPU 222 , ABB Module with warranty , CPU 222 PLC module

6ES7222-1HF22-0XA0 Siemens | S7-200 CN CPU 222

Product Snapshot

6ES722-1HF22-0XA0 is the CPU 222 for the SIMATIC S7-200 CN series. This compact PLC is ideal for small-scale automation tasks, featuring 10 digital inputs, 6 digital outputs, and 2 analog inputs. It supports a variety of communication protocols and is designed for easy integration into industrial control systems.

Key Features & Benefits

Compact Design: Fits into tight control panels
10 Digital Inputs: Suitable for various sensor signals
6 Digital Outputs: For controlling actuators and relays
2 Analog Inputs: For temperature, pressure, or flow signals
Communication Options: RS-485, MPI, and PPI interfaces
Programmable: Using STEP 7-Micro/WIN software
Wide Temperature Range: 0-55 °C operating, -25-+70 °C storage
Global Approvals: UL, CE, RoHS, REACH compliant

Technical Specifications

Parameter	Value
Part Number	6ES722-1HF22-0XA0
Series	SIMATIC S7-200 CN
Type	CPU 222
Digital Inputs	10 (24 VDC)
Digital Outputs	6 (24 VDC, 0.5 A each)
Analog Inputs	2 (0-10 V, 0-20 mA)
Communication	RS-485, MPI, PPI
Memory	16 KB user program, 1 KB data
Operating Voltage	24 VDC ±10%
Power Consumption	5 VDC @ 100 mA (from PLC backplane)
Operating Temperature	0-55 °C
Storage Temperature	-25-+70 °C
Humidity	95% RH non-condensing
Dimensions (WHD)	110 mm * 90 mm * 70 mm
Weight	0.35 kg
Certifications	UL, CE, RoHS, REACH

Typical Applications

Small-scale automation systems
Machine control in manufacturing
HVAC control systems
Simple process control applications
Educational and training purposes

Compatible Hardware

Expansion Modules: EM 231, EM 232, EM 235
Cables: Standard PLC ribbon cable
Power Supply: 24 VDC power supply
Software: STEP 7-Micro/WIN V4.0 or higher

Installation & Configuration

Mount PLC: Secure the CPU 222 on a DIN rail.
Connect Power: Ensure the 24 VDC power supply is connected.
Insert Ribbon Cable: Connect the PLC ribbon cable to the CPU.
Power Up PLC: Turn on the PLC and wait for the status LEDs to stabilize.
Program PLC: Use STEP 7-Micro/WIN to configure and upload your program.
Test System: Verify the digital and analog inputs/outputs using a multimeter.
