Name: 32 Integrated I/O Siemens 6ES7216-2BD23-0XB8 28.8V DC S7-200 CN CPU 216 DC/DC/DC
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: 6ES7216-2BD23-0XB8
Availability: InStock

Home Products Siemens PLC

32 Integrated I/O Siemens 6ES7216-2BD23-0XB8 28.8V DC S7-200 CN CPU 216 DC/DC/DC

Product Details:

Place of Origin:	China
Brand Name:	Siemens
Certification:	COC
Model Number:	6ES7216-2BD23-0XB8

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	integrated I/O Siemens 6ES7216-2BD23-0XB8 , 28.8V DC Siemens 6ES7216-2BD23-0XB8 , 28.8V DC Siemens CPU

6ES7216-2BD23-0XB8 Siemens | S7-200 CN CPU 216 DC/DC/DC

Product Snapshot

The 6ES7216-2BD23-0XB8 is the highest-performance S7-200 CN CPU, featuring 24 kB program memory, 16 DI/16 DO on-board, 6 high-speed counters (30 kHz), and 2 RS-485 ports. This unit controls medium-complexity machines without expansion racks. With on-board PID, real-time clock, and micro-SD slot, it's ideal for pumps, packaging, material-handling, and temperature-zone applications.

Key Features & Benefits

24 kB work memory - 8* larger than CPU 224; 4,096 bytes retentive
32 integrated I/O - 16 * 24 V DC inputs, 16 * 24 V DC transistor outputs
Dual RS-485 ports - Port-0 = PPI/MPI/Modbus, Port-1 = Freeport or Modbus
6 * 30 kHz high-speed counters - for encoders and length measurement
2 * 20 kHz pulse outputs - stepper/servo control without optional module
Real-time clock - 1 s accuracy, super-cap backup > 100 h
Micro-SD slot - supports firmware update, data logging, and recipe storage (≤ 32 GB)
Wide temperature range - 0 to 55°C operating, -40 to +70°C storage
Global certifications - CE, UL 508, CSA, FM Class 1 Div 2, RoHS, REACH

Technical Specifications

Part Number	6ES7216-2BD23-0XB8
Series	SIMATIC S7-200 CN
Type	CPU 216 DC/DC/DC
Power Supply	20.4 - 28.8 V DC
Digital Inputs	16 * 24 V DC, sink/source
Digital Outputs	16 * 24 V DC, transistor, 0.75 A per point
Program Memory	24 kB (16 kB user, 8 kB retentive)
Data Memory	4,096 bytes retentive
High-Speed Counters	6 * 30 kHz (single) / 4 * 20 kHz (quadrature)
Pulse Outputs	2 * 20 kHz (PTO/PWM)
Real-Time Clock	Yes, super-cap back-up > 100 h
Serial Ports	2 * RS-485 (PPI, MPI, Modbus RTU, Freeport)
SD Card	Micro-SDHC ≤ 32 GB (user supplied)
Isolation	500 V AC supply-to-logic
Power Consumption	11 W typical
Dimensions (WHD)	196 * 80 * 62 mm
Weight	0.44 kg
Operating Temp	0 - 55 °C
Storage Temp	-40 - +70 °C
Humidity	95 % RH non-condensing
Certifications	CE, UL 508, CSA, FM Class 1 Div 2, RoHS

Typical Applications

Multi-zone packaging machines (sealer, cutter, feeder)
Pump skids with VFD Modbus control
Conveyor encoder tracking & diverter control
Temperature PID autotune ovens
Small pick-and-place Cartesian robots

Expansion & Communication

Max I/O - 256 DI/DO, 32 AI/AO via EM modules
Expansion Modules - Up to 7 EM (AI, AO, RTD, TC, Ethernet, modem)
Ethernet - Add EM 277 or CM 1241-1 for PROFINET
Software - STEP 7-Micro/WIN V4.0 SP9 or SMART programming software
Cable - PC/PPI USB adapter 6ES7 901-3DB30-0XA0

Installation & Startup

Snap CPU onto 35 mm DIN-rail; plug 24 VDC supply.
Wire sensors/loads - use 0.75 mm², ferrules recommended.
Insert micro-SD if firmware update or data-log needed.
Connect PC - USB/PPI cable; auto-detect CPU in Micro/WIN.
Download program - RUN/STOP switch on front; green "RUN" LED on.
