SINUMERIK 828D Basic PPU 24x0.3 PLC CPU (6FC5370-3AA30-0AA1)

Product Snapshot

The 6FC5370-3AA30-0AA1 SINUMERIK 828D Basic PPU 24x0.3 is a compact, panel-mounted CNC and PLC solution designed for 3- to 5-axis milling, turning, and grinding machines. This integrated unit features a 1.2 GHz ARM multi-core CPU, 2 GB CNC memory, 512 KB PLC memory, and multi-protocol Ethernet support in an IP65 enclosure, reducing cabinet space by 30% and commissioning time by 40% compared to traditional CNC + PLC configurations.

Key Features & Benefits

Combined CNC + PLC in one IP65 enclosure with 3/5-axis interpolation and 1 ms IPO cycle
1.2 GHz ARM multi-core processor with 2 GB CNC RAM and 512 KB PLC RAM (80 ns bit instruction)
Multi-protocol Ethernet support including SINUMERIK Integrate, OPC-UA server, Modbus TCP, HTTP/HTTPS
On-board I/O: 24 DI, 16 DO, 4 AI, 2 AO, plus 4 * 1 MHz high-speed counters
USB 3.0 + CFast for program transfer, data backup, and service stick boot capability
Integrated safety features including Safe Torque Off (STO), SIL 3 / PL-e certified
IP65 front protection with fanless operation up to 45°C (rear heat-sink up to 55°C)
Global certifications: CE, UL 508, cUL, RoHS, REACH compliant

Technical Specifications

Part Number	6FC5370-3AA30-0AA1
Description	SINUMERIK 828D Basic PPU 24x0.3
CNC Axes	3 - 5 axes simultaneous
Interpolation cycle	1 ms (0.5 ms optional)
CPU	ARM Cortex-A72 quad-core 1.2 GHz
CNC memory	2 GB DDR4
PLC memory	512 KB user, 128 KB retentive
On-board I/O	24 DI, 16 DO, 4 AI (±10 V), 2 AO (±10 V)
High-speed counters	4 * 1 MHz, 32-bit
Ethernet	2 * 10/100/1000 RJ-45 (switch or independent)
USB	2 * USB 3.0 host
Storage	CFast 8 GB (included)
Display port	DVI-I 1920 * 1200 @ 60 Hz
Safety	Safe Torque Off (STO), SIL 3 / PL-e
Power supply	24 VDC ±20 %, 3.5 A typical, 5 A peak
Operating temp	0 - 55 °C (rear heat-sink)
Storage temp	-25 - +70 °C
Humidity	95 % RH non-condensing
Protection	IP65 front, IP20 rear
Dimensions (WHD)	483 * 220 * 65 mm (19" 4U)
Weight	4.2 kg
Certifications	CE, UL 508, cUL, RoHS, REACH

Typical Applications

3-axis vertical machining centres
5-axis portal mills
CNC lathes with C-axis & driven tools
Grinding machines (surface, cylindrical)
Retrofit of analog 810D/840D to digital 828D

Compatible Hardware

I/O expansion: 6FC5371-0AA10-0AA2 (digital), 6FC5371-0AA20-0AA2 (analog)
Servo drives: SINAMICS S120 Combi 3-axis 6SL3…-1TE…
Motors: 1FK7, 1FT7, 1PH8, 1FE1 permanent-magnet spindles
Operator panel: MCP 483 CP (mechanical) or MCP 483 PN (touch)
Software: SINUMERIK Operate v4.9+, TIA Portal v17, Startdrive v17

Installation & Startup

Panel cut-out - 465 * 204 mm; torque clips 0.8 N*m.
Connect 24 VDC - use 4 mm², torque 0.5 N*m; ripple < 5 %.
Plug servo - DRIVE-CLiQ cable to S120 Combi; motors auto-detected.
Load program - copy *.arc archive to CFast; power-cycle.
Verify LEDs - green "RDY" + blue "NCU" = normal; run "first commissioning" wizard.
