Allen-Bradley 500V AC Allen Bradley 2080-SERIALISOL Micro 800 Isolated Serial Module

1. Product Snapshot

2. Key Features & Benefits

• One isolated port – software-selectable RS-232 or RS-485, 300 – 115 200 bps
• 2.5 kV isolation – port-to-logic and port-to-power; meets IEC 60950-1
• Auto-turnaround – half-duplex RS-485 with adjustable bias & termination
• On-board LEDs – TX, RX, ERR for at-a-glance diagnostics
• Plug-and-play – snaps onto any Micro 800 CPU in < 5 s, no tools
• Wide temperature – 0…+55 °C operating, –40…+70 °C storage
• Global approvals – CE, UL 508, cULus, Class I Div 2, RoHS, REACH

3. Technical Specifications

4. Typical Applications

• Micro 850 ↔ VFD Modbus-RTU speed control
• Energy-meter ASCII read-out on Micro 870
• Barcode scanner RS-232 interface
• Remote modem (GPRS) telemetry link
• Class I Div 2 transmitter in oil & gas

5. Compatible Hardware

• Controllers: Micro 850, Micro 870, Micro 830 (V2.0+)
• Cables: 1761-CBL-PM02 (RS-232), 1761-CBL-HM02 (RS-485)
• Software: Connected Components Workbench (CCW) v12+
• Breakers: 1492-SP3R040 (0.5 A curve C) recommended

6. Installation & Start-up

1. Power down CPU – plug-in module is not hot-swappable.
2. Insert module – slide left until latch clicks.
3. Wire serial – use Belden 9841 (RS-485) or 8306 (RS-232).
4. Configure port – CCW > Plug-in > Serial > 9600-8-N-1, Modbus-RTU Master.
5. Test comms – poll slave, verify RX LED flash and data in buffer.
