Name: 8 Channel KJ3222X1-BA2 Emerson EPRO DeltaV 4–20 MA HART Temp Resistant
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: KJ3222X1-BA2
Price: 999 USD
Availability: InStock

Home Products Emerson EPRO

8 Channel KJ3222X1-BA2 Emerson EPRO DeltaV 4–20 MA HART Temp Resistant

Product Details:

Place of Origin:	Germany
Brand Name:	Emerson EPRO
Certification:	CO
Model Number:	KJ3222X1-BA2

Payment & Shipping Terms:

Price:	$999
Payment Terms:	T/T

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	8 Channel KJ3222X1-BA2 Emerson EPRO , 20MA KJ3222X1-BA2 Emerson EPRO , 8 Channel Analog Input Module

KJ3222X1-BA2 Emerson EPRO DeltaV 8-Channel 4–20 mA HART Analog Input Module

Product Description

The KJ3222X1-BA2 is a genuine Emerson DeltaV Series 2 analog input module that provides eight isolated 4-20 mA channels with HART 7 communication. Designed for critical process and safety applications, it delivers 16-bit resolution, loop-power, hot-swap capability and SIL 2 fault tolerance while operating from -40 °C to +70 °C.

Key Features & Benefits

100% OEM Emerson - serialized & factory-sealed
8 isolated 4-20 mA inputs (loop-powered)
HART 7 protocol per channel for smart-device data
16-bit resolution, ±0.1% full-scale accuracy
250 ms scan time, configurable 50-500 ms
Sensor break, short-circuit and over-range diagnostics
Hot-swappable on DeltaV rack - no shutdown
ISA G3 corrosion resistance, conformal-coated
-40 °C … +70 °C operating range
SIL 2 (IEC 61508), CE, UL 508, ATEX, IECEx certified

Technical Specifications

Parameter	Value
Model	KJ3222X1-BA2
DeltaV Series	Series 2 Traditional I/O
Channels	8 isolated 4-20 mA
Resolution	16-bit (0.0015%)
Accuracy	±0.1% FS @ 25 °C
Scan Time	250 ms (50-500 ms configurable)
HART Version	7 (field-device variables)
Loop Supply	24 VDC (module-powered)
Isolation	500 V channel-to-bus
Power	5 VDC @ 120 mA (backplane)
Operating Temp	-40 °C … +70 °C
Humidity	5% … 95% RH non-condensing
Mounting	DeltaV Traditional I/O rack, 1 slot
Approvals	SIL 2, CE, UL 508, ATEX Zone 2, IECEx

Typical Applications

Pressure, flow, level transmitters
Temperature loop measurement
Valve position feedback with HART
Safety-system analog inputs (SIL 2)
Offshore and marine process control

What's Included

1* KJ3222X1-BA2 analog input module
1* Removable 40-pin spring-clamp terminal block
Factory calibration certificate & traceability label
Quick-start guide & ESD wrist strap

Installation & Setup

Insert module into any DeltaV Traditional I/O rack slot.
Connect 4-20 mA field wiring to terminal block.
Power on--green READY LED < 5 s.
Configure channels in DeltaV Control Studio; auto-detect HART devices.
Perform loop test & SIL proof-test.
