Name: Modular Redundant 5466-253 Woodward TMR PLC 20 MA High Resolution Analog Inputs
Brand: Xiamen IntelliLink Global Electronic Products Co., Ltd
SKU: 5466-253
Price: 1,505.00 USD
Availability: InStock

Home Products Woodward Module

Modular Redundant 5466-253 Woodward TMR PLC 20 MA High Resolution Analog Inputs

Product Details:

Place of Origin:	USA
Brand Name:	Woodward
Certification:	CO
Model Number:	5466-253

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	$10-3000
Packaging Details:	original
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10 pieces one day

Contact Now

Detailed Product Description

Type:	Module	Shipping By:	DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time:	In Stock	Product Type:	Module
Payment:	T/T	Trading Term:	EXW
Highlight:	Modular Redundant 5466-253 Woodward , TMR PLC 5466-253 Woodward , TMR PLC Analog Input Module

5466-253 Woodward Analog Combo Module TMR PLC

Product Overview

The 5466-253 is a factory-built, Triple Modular Redundant (TMR) analog combo module from Woodward's MicroNet TMR family. It delivers eight high-resolution analog inputs (4-20 mA, 0-10 V) and four isolated analog outputs (4-20 mA) in a single slot--perfect for critical turbine, compressor, and engine control loops requiring SIL 3 safety integrity.

Key Features & Benefits

100% OEM Woodward--serialized & anti-static sealed
TMR architecture: triple ADC & DAC per channel for fault-tolerant voting
8 differential analog inputs (4-20 mA, 0-10 V, RTD/TC option)
4 isolated analog outputs (4-20 mA) with HART pass-through
16-bit resolution, ±0.1% full-scale accuracy
1 ms scan/update rate for fast control loops
Channel-level LEDs: OK, Fault, Voting status
Hot-swappable in MicroNet TMR rack--no shutdown
-40°C … +70°C operating, conformal-coated PCB
CE, UL Listed, ABS, SIL 3 (IEC 61508) certified

Technical Specifications

Parameter	Value
Part Number	5466-253
Series	Woodward MicroNet TMR
Function	8 AI / 4 AO Analog Combo
Input Types	4-20 mA, 0-10 V, RTD, TC (configurable)
Input Channels	8 differential, 16-bit
Output Channels	4 isolated, 4-20 mA, 16-bit
Accuracy	±0.1% FS @ 25°C
HART	Revision 7 pass-through on outputs
Scan/Update	1 ms per channel
Isolation	500 VAC channel-to-bus
Power	24 VDC ±10%, 10 W max
Operating Temp	-40°C … +70°C
Humidity	5% … 95% RH non-condensing
Mounting	MicroNet TMR 19 in. rack (1 slot wide)
Approvals	CE, UL, ABS, SIL 3, ATEX Zone 2, IECEx

Typical Applications

Gas & steam turbine control (Frame 5/6/7/9)
Compressor anti-surge & load-sharing loops
Emergency trip & fuel-valve positioning
Marine propulsion & diesel-genset control
Safety-critical process loops (SIL 3)

What's Included

1* 5466-253 TMR analog combo module
1* Removable 56-pin spring-clamp terminal block
Factory calibration certificate & SIL 3 conformity report
Quick-start guide & ESD wrist strap

Installation & Setup

Insert module into any MicroNet TMR rack slot.
Connect field cables to removable terminal; torque to 0.5 N*m.
Power up rack--green HEALTH LED in < 5 s.
Launch Woodward TMR Builder; auto-detect module, configure scaling & voting.
Perform loop test and SIL 3 proof-test per IEC 61508.
