MicroNet Plus Woodward Module 8 Channel Analog Output Woodward 5466-348

MicroNet Plus Woodward Module 8 Channel Analog Output Woodward 5466-348

  • MicroNet Plus Woodward Module 8 Channel Analog Output Woodward 5466-348
MicroNet Plus Woodward Module 8 Channel Analog Output Woodward 5466-348
Product Details:
Place of Origin: USA
Brand Name: Woodward
Certification: CO
Model Number: 5466-348
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $399
Packaging Details: original
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10 pieces one day
Contact Now
Detailed Product Description
Type: Module Shipping By: DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time: In Stock Product Type: Module
Payment: T/T Trading Term: EXW
Highlight:

MicroNet Plus Woodward 5466-348

,

8 Channel Woodward 5466-348

,

Analog Output Woodward 5466-348

5466-348 Woodward MicroNet Plus 8-Channel Analog Output Module
Product Description
The 5466-348 is a genuine Woodward analog output module for MicroNet Plus control systems. Providing eight isolated 4-20 mA or ±10 VDC channels with 14-bit resolution, it delivers high-precision control of valves, actuators and variable-speed drives while meeting SIL 2 requirements for turbines, compressors and safety-critical processes.
Key Features & Benefits
  • 100 % OEM Woodward - serialized & factory-sealed
  • 8 isolated analog outputs (4-20 mA or ±10 V per channel)
  • 14-bit resolution, ±0.1 % full-scale accuracy
  • 2 ms update time, configurable ramp & limit
  • Over-range, short-circuit & open-loop diagnostics
  • Hot-swap in MicroNet Plus rack - no shutdown
  • Redundant 24 VDC power inputs with diode OR-ing
  • -40 °C … +85 °C operating, conformal-coated
  • SIL 2 (IEC 61508), CE, UL 508, ABS, ATEX certified
Technical Specifications
Parameter Value
Model 5466-348
Manufacturer Woodward
Platform MicroNet Plus
Channels 8 isolated analog outputs
Output Ranges 4-20 mA or ±10 V (DIP-selectable)
Resolution 14-bit (0.006 %)
Accuracy ±0.1 % FS @ 25 °C
Update Time 2 ms per channel
Load (Current) 0-750 Ω (4-20 mA)
Load (Voltage) ≥ 1 kΩ (±10 V)
Isolation 2 kV channel-to-bus
Power 24 VDC (18-36 V), 15 W max
Operating Temp -40 °C … +85 °C
Humidity 5 % … 95 % RH non-condensing
Mounting MicroNet Plus 6U rack, 1 slot
Approvals SIL 2, CE, UL 508, ABS, ATEX Zone 2
Typical Applications
  • Gas/steam turbine valve positioning
  • Compressor surge-control actuators
  • Generator excitation field reference
  • Safety-system analog outputs (SIL 2)
  • Marine & offshore process control
What's in the Box
  • 1× 5466-348 analog output module
  • 1× Removable 20-pin spring-clamp terminal block
  • Factory calibration certificate & traceability label
  • Quick-start guide & ESD wrist strap
Installation & Setup
  1. Insert module into MicroNet Plus rack slot.
  2. Connect 24 VDC power and field wiring.
  3. Power on--green STATUS LED < 10 s.
  4. Configure ranges and limits in Woodward GAP software.
  5. Perform loop test & SIL 2 proof-test.
