High Speed Woodward 8444-1091 100 MHz 16 Isolated 24 VDC For Gas And Steam Turbines

High Speed Woodward 8444-1091 100 MHz 16 Isolated 24 VDC For Gas And Steam Turbines

  • High Speed Woodward 8444-1091 100 MHz 16 Isolated 24 VDC For Gas And Steam Turbines
High Speed Woodward 8444-1091 100 MHz 16 Isolated 24 VDC For Gas And Steam Turbines
Product Details:
Place of Origin: USA
Brand Name: Woodward
Certification: CO
Model Number: 8444-1091
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $1299
Packaging Details: original
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10 pieces one day
Contact Now
Detailed Product Description
Type: Module Shipping By: DHL/UPS/EMS/FEDEX/TNT Or Agent Etc
Lead Time: In Stock Product Type: Module
Payment: T/T Trading Term: EXW
Highlight:

16 Isolated Woodward 8444-1091

,

Steam Turbines Woodward 8444-1091

,

Steam Turbines Digital Control Module

8444-1091 Woodward Digital Control Module for Gas & Steam Turbines
Product Description
The 8444-1091 is a genuine Woodward digital control module engineered for gas and steam turbine applications. Integrating seamlessly with MicroNet Plus or Atlas control systems, it provides high-speed I/O, deterministic control loops and SIL 2 fault tolerance for critical speed, temperature and load-control functions.
Key Features & Benefits
  • 100% OEM Woodward - serialized & factory-sealed
  • Digital control and I/O processing for gas/steam turbines
  • Compatible with MicroNet Plus & Atlas platforms
  • High-speed 100 MHz RISC processor with floating-point unit
  • 16 isolated digital inputs, 8 relay outputs, 4 analog I/O
  • On-board speed sensor interface (magnetic pickup)
  • Redundant 24 VDC power inputs with diode OR-ing
  • Hot-swap capable in MicroNet Plus rack - no shutdown
  • -40 °C … +85 °C operating, conformal-coated
  • SIL 2 (IEC 61508), CE, UL 508, ABS, ATEX certified
Technical Specifications
Parameter Value
Model 8444-1091
Manufacturer Woodward
Platform MicroNet Plus / Atlas
Processor 100 MHz RISC with FPU
Digital Inputs 16 isolated 24 VDC
Digital Outputs 8 Form-C relays, 5 A @ 250 VAC
Analog I/O 4 universal ±10 V / 4-20 mA
Speed Input Magnetic pickup, 1 Hz-20 kHz
Communication RS-485 Modbus RTU, CAN, Ethernet option
Power 24 VDC (18-36 V), 15 W max
Isolation 2 kV channel-to-bus
Operating Temp -40 °C … +85 °C
Humidity 5% … 95% RH non-condensing
Mounting MicroNet Plus 6U rack, 1 slot
Approvals SIL 2, CE, UL 508, ABS, ATEX Zone 2
Typical Applications
  • Gas turbine speed and load control
  • Steam turbine temperature and inlet pressure control
  • Compressor surge prevention and load sharing
  • Generator excitation and synchronization
  • SIL 2 safety-critical turbine protection loops
What's in the Box
  • 1× 8444-1091 digital control module
  • 1× Removable 48-pin spring-clamp terminal block
  • Factory calibration certificate & traceability label
  • Quick-start guide & ESD wrist strap
Installation & Setup
  1. Insert module into MicroNet Plus rack slot.
  2. Connect 24 VDC power and field wiring.
  3. Power on--green STATUS LED < 10 s.
  4. Configure I/O and control loops in Woodward GAP software.
  5. Perform loop test & SIL 2 proof-test.
