Honeywell PLC 6580500051 Honeywell Pressure Transmitter 10bar 20mA 1/2" NPT

The Honeywell 6580500051 Industrial Pressure Transmitter converts 0-10 bar gauge pressure into a two-wire 4-20 mA signal. Built on Honeywell's proven piezo-resistive sensor platform, this transmitter delivers reliable performance in demanding industrial environments.

• ±0.25% full-scale accuracy for precise measurements
• All-stainless 316L wetted parts for corrosion resistance
• 1/2" NPT male process connection for easy installation
• IP66/67 rated field housing withstands wash-down and dust
• Wide operating range of -40 to +85°C without additional heat-sink

Ideal for pumps, compressors, HVAC systems, water treatment, and pneumatic skids where reliable, cost-effective pressure measurement is required.

• 0.25% accuracy - reduces process variability for improved control
• 316L SS diaphragm - compatible with water, oil, and gas applications
• 4-20 mA output - directly connects to any PLC/DCS analog card
• -40°C start-up - operates in cold environments without heated enclosures
• IP67 housing - withstands rain, wash-down, and dust exposure
• 10.5-45 V loop - compatible with standard 24 VDC plant power
• Zero/span pots - allows field adjustment without HART tool

• Isolating barrier: MTL 5541 (Ex ia loop)
• Cable gland: Hummel M20 x 1.5, IP68
• Manifold valve: 316L 2-valve, 1/2" NPT
• Snubber: 0.8 mm orifice, 1/2" NPT

• 6580500051 pressure transmitter
• Calibration certificate (5-point, NIST traceable)
• CD with manual & 2-D drawing
• Protective plastic cap on process port
• Quick-install card for easy setup
