3300 XL 21504-000-040-05-02 Bently Nevada 4 Metre Armour Extension Cable Bently Nevada Parts

3300 XL 21504-000-040-05-02 Bently Nevada 4 Metre Armour Extension Cable Bently Nevada Parts

  • 3300 XL 21504-000-040-05-02 Bently Nevada 4 Metre Armour Extension Cable Bently Nevada Parts
  • 3300 XL 21504-000-040-05-02 Bently Nevada 4 Metre Armour Extension Cable Bently Nevada Parts
3300 XL 21504-000-040-05-02 Bently Nevada 4 Metre Armour Extension Cable Bently Nevada Parts
Product Details:
Place of Origin: USA
Brand Name: Bently Nevada
Certification: COC
Model Number: 21504-000-040-05-02
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $500
Packaging Details: original
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10 pieces one day
Contact Now
Detailed Product Description
Highlight:

3300 XL 21504-000-040-05-02 Bently Nevada

,

4 Metre 21504-000-040-05-02 Bently Nevada

,

Extension Cable Bently Nevada Parts

21504-000-040-05-02 Bently Nevada 3300 XL 4-Metre Armour Extension Cable
Product Snapshot
21504-000-040-05-02 is a 4-metre armour extension cable that bridges any 3300 XL 5 mm or 8 mm proximity probe to the driver. The miniature -76 mil connector, stainless-steel armour and blue fluoro-polymer jacket deliver oil, steam and UV resistance for turbines, compressors and pumps operating up to 150 °C.

Key Features & Benefits
  • Exact 4 m length - eliminates excess coiling, reduces install time
  • -76 mil miniature connector - 10-32 UNF, gold-plated contacts
  • Stainless-steel armour - crush-proof to 1 000 N, rodent resistant
  • Fluoro-polymer jacket - chemical, ozone & steam resistant, blue colour-code
  • ±0.5 % impedance tolerance - ensures < 1 % system accuracy
  • Wide temperature - -55 °C to +150 °C continuous
  • Global approvals - CE, ATEX Cat 3, RoHS, REACH

Technical Specifications
Parameter Value
Part Number 21504-000-040-05-02
Function 3300 XL Extension Cable
Length 4.0 m (13.1 ft)
Connector Probe 10-32 UNF male (-76)
Connector Driver 10-32 UNF female (-76)
Armour Stainless-steel, OD 4.8 mm
Jacket Fluoro-polymer, blue
Capacitance 69 pF/m nominal
Impedance 50 Ω ±0.5 % @ 1 MHz
Temperature -55 - +150 °C
Min Bend Radius 25 mm static / 50 mm dynamic
Protection IP68 when mated
Weight 0.22 kg
Certifications CE, ATEX Cat 3, RoHS, REACH

Typical Applications
  • Gas & steam turbine shaft vibration
  • Centrifugal compressor axial position
  • Pump bearing temperature + vibration combo
  • Offshore platforms (salt-spray, UV)
  • High-temperature steam valve position

Compatible Components
  • Probes: 3300 XL 5 mm / 8 mm, -76 thread
  • Drivers: 3300 XL 5 m driver, -76 input
  • Monitors: 3500/42M, 3500/44M, 3500/45
  • Tools: 21500-000-080 torque wrench, 13849-01 gland kit

Installation Steps
  1. Route cable - maintain 50 mm bend radius.
  2. Hand-tighten connectors, then 1/8 turn with wrench.
  3. Seal entry - use 13849-01 gland for IP68.
  4. Verify continuity < 1 Ω, insulation > 100 MΩ.
  5. Enter 4.0 m cable length in 3500 Rack Config Utility.
