40 KHz 21505-000-040-10-02 Bently Nevada Proximity Probe 5Mm M10×12M Cable

21505-000-040-10-02 is a factory-made 40 cm (16 in) 10-pin extension cable that links the 3500/05 Mini-Rack backplane to remote termination blocks, distributed I/O bricks, or adjacent mini-racks.

Moulded polarised connectors and fully-shielded twisted pairs maintain IEC 61000-4-3 EMC immunity and API 670 mechanical integrity, cutting field wiring time by 30%.

• Exact fit - 10-pin polarised plug/socket, keyed to prevent mis-mating
• 40 cm length - ideal for side-by-side mini-rack or bulk-head pass-through
• Shielded pairs - 100% foil + drain wire, < 1 Ω end-to-end
• Oil & UV resistant - PUR jacket, -30…+90 °C, IP65 when mated
• Hot-swap compatible - rack remains powered during cable change
• Global approvals - CE, UL AWM 2464, ATEX Cat 3, RoHS, REACH

• Side-by-side 3500/05 mini-rack expansion
• Remote termination block inside ATEX Ex e box
• Bulk-head feed-through on turbine auxiliary skid
• Retrofit of legacy 3300 racks to 3500/05 without re-wiring
• Offshore Zone 2 vibration monitoring panels

• Rack: 3500/05 Mini-Rack (any size)
• Backplane: 21505-000-xxx-10-01 (motherboard)
• Termination: 21505-025-xxx-10-02 (remote terminal block)
• Cable Lengths: 020 (20 cm), 040 (40 cm), 100 (1 m), 200 (2 m) - same day stock
• Software: 3500 Rack Configuration Utility (RCU) - auto-detects cable presence

1. Power down rack OR perform hot-swap within 30 s.
2. Release latch on existing 10-pin header; pull straight out.
3. Insert 21505-000-040-10-02 until latch clicks; verify key-way alignment.
4. Route cable - maintain ≥ 45 mm bend radius; secure with P-clamp.
5. Power up - green "System OK" LED indicates continuity.
